B50A400 Non Grain Oriented Electrical steel
According to the study, the global silicon steel market size has been growing steadily in the past few years, and the main driving factors include globalization, technological progress and government policy support. When we work in the operation if the higher the frequency, the greater the eddy current loss, then we choose the silicon steel sheet should be thinner.
B50A400 steel Mechanical Properties
|
Grade |
Nominal thickness（mm） |
tensile strength L（N/mm2） |
Yield Strength L（N/mm2） |
Elongation L（%） |
Hardness HV1 |
Bending frequency (times) |
Stacking factor（%） |
|
B50A400 |
0.50 |
7.65 |
454 |
302 |
32 |
170 |
≥15 |
B50A400 steel sheet Electromagnetic induction standard
|
Grade |
Nominal thickness（mm） |
Theoretical density（kg/dm3） |
Maximum core loss P17/50 |
minimum magnetic induction（T） |
|
B50A400 |
0.50 |
7.65 |
4.00 |
1.63 |
B50A400 silicon steel are not only as low-priced as the goods of other markers, but they are distinctly superior in the following respects.
1、 Significant reduction in iron loss at high frequency
2、 High maximum permeability and low coercivity
3、Excellent magnetic properties
4、 The smoothness of the surface has reached a high level
5、The magnetic properties of the product stacking coefficient and material are improved
